Machined metal housing block with a large bore and side port

Precision Shaft

TM-SH-002

Precision ground shaft with tight tolerance control for rotary and transmission applications.

Material
Alloy Steel 42CrMo4
Surface Finish
Ra 0.8
Tolerance
±0.005mm
Hardness
HRC 58-62
Certification
ISO 9001:2015
Request a Quote Download Datasheet
Diameter
25 mm
Length
180 mm
Straightness
0.005 mm
Runout
0.008 mm
Heat Treatment
Quenched & Tempered
Surface
Ground

Produced on CNC turning and grinding centers with in-process gauging, our precision shafts deliver consistent diameter, roundness, and surface finish across production batches.

Shafts are turn-quenched-tempered, ground and lapped to a Ra 0.8 sealing surface, with straightness and runout checked between centers on every part. We support batch sizes from single prototypes to monthly rolling orders, and can supply with keyed or threaded end options on request.

  • Industrial machinery and equipment assemblies
  • Fluid handling and pump systems
  • Custom OEM applications
